Dahua DH-HAP120 - High-Fidelity CCTV Pickup Microphone, Omnidirectional, 10-70m, 80Hz-16kHz, 12V DC, Aluminum
-
Dahua DH-HAP120 | CCTV Microphone | High Fidelity | Omnidirectional | 10-70mIn stock$17.36* Taxes not included
Capture clear and natural audio to complement professional surveillance systems. The Dahua DH-HAP120 features a high-fidelity omnidirectional microphone with a 1070 m coverage range, 80Hz16kHz frequency response, and 58dB signal-to-noise ratio. Its compact aluminum housing operates on 12V DC and provides protection against electrostatic discharge, lightning, and power polarity reversal. Ideal for CCTV installations requiring reliable audio pickup.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yappy or ACH Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Dahua |
| Model | DH-HAP120 |
| Type | Microphone |
Specifications |
|
| Specifications | - Scope: 1070 m
- Sensitivity: -34 3 dB - Frequency Response: 80 Hz16 kHz - Directional Characteristic: Omni-directional - SNR: 58 dB - Dynamic Range: 74 dB - Maximum Sustainable Sound Pressure: 110 dB SPL (1 kHz, THD 1%) - Output Impedance: 600 (non-equilibrium) - Output Signal Amplitude: 2.5 Vpp/88 dB SPL - Microphone: Electret condenser microphone - Working Voltage: DC 12 V - Working Current: 40 mA - Working Temperature: -30 C to +70 C - Material: Aluminum - Interface: RCA female connector and DC power connector - Certification: CE/FCC |
Features |
|
| Features | - High-fidelity audio pickup
- High-sensitivity microphone head for clear and natural sound - Omni-directional audio capture - Designed for sound acquisition within 1070 m - Basic noise reduction - Lightning protection - Power polarity reversal protection - Electrostatic protection - Aluminum construction - CE and FCC certified |
Dimensions |
|
| Dimensions(cm) | 4.0 x 4.0 x 2.0 cm |
| Weight | 0.048 kg (0.11 lb) |
Warranty
Warranty:
Dahua Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Dahua for you. You may also contact Dahua directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Dahua and are final.
