Dahua DHI-ASI1202M - Fingerprint Access Controller, Card & Fingerprint, IP65, IK10, Zinc Alloy, Black
-
Dahua DHI-ASI1202M | Fingerprint Access Controller | Card & Fingerprint | IP65 | IK10 | BlackIn stock$69.65* Taxes not included
The Dahua DHI-ASI1202M is a standalone fingerprint access controller designed for outdoor access control. It supports card, fingerprint, and combined card-and-fingerprint authentication, with capacity for up to 30,000 users, 3,000 fingerprints, 30,000 cards, and 150,000 records. Its zinc alloy housing with IP65 and IK10 protection provides durability for demanding installations.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yappy or ACH Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Dahua |
| Model | DHI-ASI1202M |
| Type | Card Reader, Fingerprint Reader, Intercom |
Specifications |
|
| Specifications | Network Protocol: IPv4; TCP
OSDP Protocol: Yes SDK and API: Yes Casing: Zinc alloy Buzzer: Yes Unlock Mode: Fingerprint / Card Card Type: IC card Card Reading Frequency: 13.56MHz Card Reading Distance: 1cm3cm Fingerprint Sensor: Optical Fingerprint Verification: 1:N Fingerprint Comparison Time: 1.5s Fingerprint Recognition Time: 0.5s User Capacity: 30,000 Fingerprint Capacity: 3,000 Card Capacity: 30,000 Record Capacity: 150,000 Multiple Authentication: Card / fingerprint Period List: 128 Holiday Period: 128 Network Update: Yes First Card Unlock: Yes Remote Verification: Yes Blocklist/Allowlist: Yes Peripheral Card Reader: 1 × RS-485, 1 × Wiegand Real-Time Surveillance: Yes Group Combination: Yes Register: Yes RS-485: 1 Wiegand: 1, input and output ports are the same USB: 1 × USB 2.0 Network: 1 × RJ-45, 10Mbps/100Mbps self-adaptive Alarm Input: 1 digital input Alarm Output: 1 relay Alarm Linkage: Yes Exit Button: 1 Door Status Detection: 1 Lock Control: 1 Anti-Passback: Yes Tamper Alarm: Yes Duress Alarm: Yes Door Sensor Timeout Alarm: Yes Intrusion Alarm: Yes Illegal Card Exceeding Threshold: Yes Duress Fingerprint: Yes Power Adapter: Optional Power Supply: 12V DC 1A Protection Grade: IP65 Impact Protection: IK10 Operating Environment: Outdoor |
Features |
|
| Package Contents | 1x Access Controller
1x Bracket |
Dimensions |
|
| Dimensions (mm) | 54.8 × 159.2 × 35.0mm |
| Weight | 0.7kg |
Warranty
Warranty:
Dahua Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Dahua for you. You may also contact Dahua directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Dahua and are final.
