Dahua DHI-ASR1102A - Fingerprint IC Card Reader, MIFARE, 13.56 MHz, RS-485, Indoor, Black
-
Dahua DHI-ASR1102A | Fingerprint IC Card Reader | MIFARE | RS-485 | BlackIn stock$53.20* Taxes not included
The Dahua DHI-ASR1102A is an indoor fingerprint and IC card reader designed for access control systems. It supports MIFARE cards operating at 13.56 MHz, fingerprint authentication with 360 recognition and up to 3,000 fingerprint templates. The reader communicates through RS-485 and provides buzzer and blue backlight indicators, with tamper, overcurrent and overvoltage protection.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yappy or ACH Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Dahua |
| Model | DHI-ASR1102A |
| Type | Card Reader, Fingerprint Reader |
Specifications |
|
| Specifications | - Product Type: Card Reader
- Unlock Mode: Card; Fingerprint - Card Type: IC Card - Card Format: MIFARE 13.56 MHz - Card Reading: Contactless - Card Reading Distance: 05 cm - Fingerprint Sensor Type: Optical - Fingerprint Recognition: 360 - Fingerprint Verification Mode: 1:N - Fingerprint Capacity: 3,000 - Fingerprint Recognition Response Time: 0.5 s - Fingerprint Recognition Time: 1.5 s - False Acceptance Rate (FAR): 0.00004% - False Rejection Rate (FRR): 0.15% - Response Time: 0.1 s - Buzzer: Yes - RS-485: Yes - Wiegand: Yes - Tamper Alarm: Yes - Power Supply: 915 VDC, 100 mA - Operating Environment: Indoor - Installation: Surface mount |
Features |
|
| Package Contents | 1 × DHI-ASR1102A Device
1 × Mounting Bracket 1 × Screw Kit 1 × Quick Start Guide 1 × Legal and Regulatory Information Leaflet |
Dimensions |
|
| Dimensions (mm) | 165.5 × 56.6 × 29 mm |
| Weight | 0.25 kg |
Warranty
Warranty:
Dahua Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Dahua for you. You may also contact Dahua directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Dahua and are final.
