Hikvision AcuSense Series - DVR System, 4 Channels, 8MP, Up to 12TB per Disk, HDMI, VGA
-
Hikvision AcuSense Series | DVR | 4 Channels | 8MPIn stockS/.938.84
The Hikvision iDS-7204HTHI-M2/XT is designed for high-definition analog cameras (HDTVI, AHD, HDCVI, CVBS) and IP cameras. Thanks to its H.265 Pro+ compression ratings, support for up to 8 MP (4K) resolution, and dual SATA interfaces for drives up to 12 TB, it delivers excellent performance for ultra-detailed video recording and efficient system storage and bandwidth management. Additionally, it features intelligent perimeter protection for human and vehicle analysis, facial detection with up to 2-channel picture comparison, and simultaneous HDMI and VGA video outputs.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yape or Bank Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Hikvision |
| Model | iDS-7204HTHI-M2/XT |
| Type | DVR |
Recording Details |
|
| Channels | 4 Channels |
| Inputs | 4x Coaxial |
| Audio Inputs | - 1-ch RCA (up to 4-ch optional)
- 4-ch via coaxial cable |
| Disk Slots | 2x SATA Interfaces |
| Max Capacity | Up to 12TB |
| Max Resolution | 4k |
| Max Frame Rate | - 12 fps at 8 MP
-15 fps at 8 MP - 20 fps at 3K - 20 fps at 5 MP - 25 fps at 3K - 25 fps at 4 MP - 25 fps at 1080p - 30 fps at 4 MP - 30 fps at 1080p |
| Compression Format | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
Outputs Details |
|
| PoE | No |
| Audio Outputs | 1-ch RCA (Linear, 1 K) |
| Other Ports | - 1x RJ45 10/100 Mbps self-adaptive Ethernet interface
- 1x RS-485 (half-duplex) - 1x USB 2.0 (Front panel) - 1x USB 3.0 (Rear panel) |
| Video Ports | 1x HDMI 1x VGA |
| Resolution per Ouputs | - HDMI: 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
Features |
|
| Features | - 2-ch Face picture comparison alarm
- 4-ch Human/Vehicle analysis - Face picture comparison and face picture search - Facial detection and capture - HDMI/VGA simultaneous output - Support main stream or sub stream - Supporting coaxitron connection - Up to 16 face picture libraries |
Dimensions |
|
| Dimensions(cm) | 38.4 cm × 5.2 cm × 31.3 cm |
| Weight | 1.16 kg |
Warranty
Warranty:
Hikvision Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Hikvision for you. You may also contact Hikvision directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Hikvision and are final.
