Hikvision DS-PM1-O1L-WB - Wireless Relay Module for Alarm Systems, 1 Relay Output, 5 A
-
Hikvision DS-PM1-O1L-WB | Wireless Relay Module | 5 AIn stockS/.104.81
Automate security devices with the Hikvision DS-PM1-O1L-WB wireless relay module, designed for integration with compatible AX PRO alarm systems. Its 433 MHz two-way communication with AES-128 encryption enables wireless device control through a relay output rated up to 5 A at 36 VDC. It includes a NO/NC tamper alarm input and supports scenario settings based on events, schedules, or manual operation. Its compact design allows for discreet indoor installation.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yape or Bank Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Hikvision |
| Model | DS-PM1-O1L-WB |
| Type | Wireless Control |
Specifications |
|
| Specifications | - Product type: Wireless relay module
- Series: AX PRO - RF frequency: 433 MHz - RF communication: Two-way - RF modulation: 2GFSK - Wireless range: Up to 800 m - Wireless security: AES-128 encryption - Power supply: 724 V DC - Relay output: 1, NO/NC, 036 V DC, maximum 5 A - Alarm input: 1 tamper input, NO/NC - Serial port: 1, for debugging - LED indicators: 3 registration/signal, power, relay status - Scenario settings: Alarm, operation, fault, schedule, manual - Operating temperature: -10 C to 55 C - Operating humidity: 10%90% - Installation: Wall mounting - Housing material: Plastic - Color: White |
Features |
|
| Features | - Two-way wireless communication at 433 MHz.
- AES-128 encrypted communication. - Remote relay control through the app, keyfob or keypad. - Automation scenarios triggered by different events. - One tamper input for alarm integration. - Compact housing for discreet installation. |
Dimensions |
|
| Dimensions (mm) | 38 × 25 × 18 mm |
| Weight | 28.5 g |
Warranty
Warranty:
Hikvision Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Hikvision for you. You may also contact Hikvision directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Hikvision and are final.
