Mercusys MS106LP - PoE+ Switch, 6 Ports, Fast Ethernet, 10/100 Mbps, 1.2Gbps
-
Mercusys MS106LP | 6 Ports | 1.2GbpsIn stockS/.105.15
Connect and power your network devices easily with the Mercusys MS106LP PoE+ switch. It features 6 Fast Ethernet 10/100 Mbps ports, including 4 PoE+ ports with a total power budget of up to 40W, making it suitable for IP cameras, access points, and compatible phones. Its plug-and-play installation simplifies setup, while the compact design fits easily into home and small business networks. Improve your connectivity with a practical and efficient networking solution.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yape or Bank Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Mercusys |
| Model | MS106LP |
Features |
|
| Type | Unmanaged |
| Ports | 6 Ports |
| Port Features | 6 × 10/100 Mbps RJ45 ports; ports 14 support PoE+; auto-negotiation; Auto MDI/MDIX. |
| Transfer Rate | 10/100 Mbps at half duplex
20/200 Mbps at full duplex. |
| Bandwidth | 1.2 Gbps switching capacity. |
| Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x; IEEE 802.3af/at compatible powered devices. |
| Form Factor | Desktop, Wall-Mountable |
| Network Management | Unmanaged |
| Features | - 4 PoE+ ports with up to 30 W per port.
- 40 W total PoE power budget. - Extend Mode with transmission distance up to 250 m; port speed decreases to 10 Mbps in this mode. - Isolation Mode for traffic separation. - PoE Auto Recovery for unresponsive powered devices. - Plug and Play installation. - Fanless design for silent operation. - Durable metal casing. - 2 KB jumbo frame. - 2K MAC address table. - Store-and-Forward switching. |
| Dimensions(cm) | 9.98 × 9.8 × 2.5 cm |
Warranty
Warranty:
Mercusys Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Mercusys for you. You may also contact Mercusys directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Mercusys and are final.
