Mercusys MS120GP - Gigabit PoE+ Switch, 20 Ports, 40Gbps
-
Mercusys MS120GP | 20 Ports | 40GbpsIn stockS/.588.05
Power your network with the Mercusys MS120GP Gigabit PoE+ switch, ideal for video surveillance, offices, and business networks. It features 20 ports: 16 Gigabit PoE+ ports, 2 Gigabit RJ45 ports, and 2 Gigabit SFP slots, with a total PoE power budget of 192W. Extend Mode supports data and power transmission over distances of up to 250 meters, while PoE Auto Recovery and isolation and priority modes help improve network reliability and traffic management. Upgrade your infrastructure with this practical rackmount networking solution.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yape or Bank Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Mercusys |
| Model | MS120GP |
Features |
|
| Type | Unmanaged |
| Ports | 20 Ports |
| Port Features | - 16 × 10/100/1000 Mbps PoE+ RJ45 ports.
- 2 × 10/100/1000 Mbps non-PoE RJ45 ports. - 2 × Gigabit SFP slots. - Auto-Negotiation. - Auto MDI/MDIX. |
| Transfer Rate | 10/100/1000 Mbps Ethernet
Gigabit SFP connectivity. |
| Bandwidth | 40 Gbps switching capacity. |
| Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at. |
| Form Factor | Rack-Mountable |
| Network Management | Unmanaged |
| Features | - 16 Gigabit PoE+ ports.
- Up to 30 W per PoE+ port. - 192 W total PoE power budget. - Extend Mode for transmission up to 250 m, with port speed reduced to 10 Mbps in this mode. - Priority Mode for ports 14. - Isolation Mode for ports 18 and 916. - PoE Auto Recovery on ports 116. - Plug and Play installation. - Store-and-Forward switching. - IEEE 802.3x Flow Control. - Automatic MAC address learning and aging. - Metal casing. - Two fans. - Physical security lock. |
| Dimensions(cm) | 44 × 18 × 4.4 cm |
Warranty
Warranty:
Mercusys Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Mercusys for you. You may also contact Mercusys directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Mercusys and are final.
