TP-Link Omada SX6632YF - L3 Managed Switch, 26 Ports, 10G SFP+ and 25G SFP28, 820Gbps
-
TP-Link Omada SX6632YF | 26 Ports | 820GbpsIn stockS/.14,882.66
Upgrade your business network infrastructure with the TP-Link Omada SX6632YF managed switch, designed for enterprise networks, data centers, and high-performance aggregation. It features 26 1/10 Gbps SFP+ slots and 6 10/25 Gbps SFP28 slots, delivering 820 Gbps of switching capacity. Layer 3 routing, physical stacking of up to 8 units in standalone mode, and centralized Omada SDN management provide scalability and control. Hot-swappable power supply modules and fans help improve network availability and reliability.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yape or Bank Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | TP-Link |
| Model | SX6632YF |
Features |
|
| Type | Managed |
| Ports | 26 Ports |
| Port Features | 26 × 1/10 Gbps SFP+ slots
6 × 1/10/25 Gbps SFP28 slots Physical stacking through 25G SFP28 ports. |
| Transfer Rate | Up to 10 Gbps per SFP+ slot and up to 25 Gbps per SFP28 slot. |
| Bandwidth | 820 Gbps switching capacity; 410 Gbps forwarding bandwidth. |
| Standards | IEEE 802.1Q VLAN, IEEE 802.1p, IEEE 802.3x Flow Control, IEEE 802.3ad LACP, IEEE 802.1D STP, IEEE 802.1w RSTP, IEEE 802.1s MSTP, IEEE 802.1X. |
| Form Factor | Rack-Mountable |
| Network Management | Managed |
| Features | - 26 × 10G SFP+ slots and 6 × 25G SFP28 slots.
- Layer 3 routing: Static Routing, RIP, OSPF, ECMP, VRRP, PIM-DM and PIM-SM. - Physical stacking of up to 8 units in standalone mode or 4 in Omada controller mode. - Stacking bandwidth up to 300 Gbps using six stacking ports. - Centralized management through the Omada SDN controller. - Standalone management via Web GUI, CLI, SNMP and RMON. - VLAN, link aggregation, spanning tree and loopback detection. - ERPS ring protection and link redundancy features. - QoS with 8 priority queues, 802.1p and DSCP prioritization. - Security features including ACL, port security, DoS defense, 802.1X and Dynamic ARP Inspection. - DHCP Server and DHCP Relay. - Four hot-swappable fans with N+1 redundancy. - Redundant, hot-swappable power supply support. - 128K MAC address table. - 8 MB packet buffer and support for 9 KB Jumbo Frames. - Español: |
| Dimensions(cm) | 44 × 4.4 × 38 cm |
Warranty
Warranty:
TP-LINK Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with TP-LINK for you. You may also contact TP-LINK directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by TP-LINK and are final.
