TP-Link VIGI NVR4016H - Network Video Recorder NVR, 16 IP Channels, 320 Mbps Bandwidth, 4x SATA Interfaces, Dual 4K HDMI Output, H.265+
-
TP-Link VIGI | NVR | 16 Channels | 4x SATA HDD | Dual 4K HDMIIn stockS/.1,460.30
The TP-Link VIGI NVR4016H network video recorder is designed for high-density commercial and enterprise IP surveillance systems. Thanks to its robust 320 Mbps incoming and outgoing bandwidth, it delivers seamless live view and synchronous playback across 16 channels with crystal-clear 4K HDMI video output. It features 4x SATA interfaces supporting hard drives up to 16 TB each for massive long-term storage retention, efficiently optimized by H.265+ smart compression technology. Additionally, it incorporates 2 independent HDMI outputs, 1 VGA output, dual Gigabit Ethernet ports, and universal ONVIF profile compliance for advanced remote monitoring via web browsers or Android and iOS mobile devices.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yape or Bank Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | TP-Link |
| Model | VIGI NVR4016H |
| Serie | VIGI |
| Type | NVR |
Recording Details |
|
| Channels | 16 Channels |
| Inputs | 2x RJ-45 |
| Audio Inputs | 1-channel RCA Input |
| Disk Slots | 4 x SATA Interfaces |
| Max Capacity | Up to 64TB |
| Max Resolution | 4k |
| Max Frame Rate | 25 fps / 30 fps |
| Compression Format | H.265+, H.265, H.264+, H.264 |
Outputs Details |
|
| PoE | No |
| Audio Outputs | 1-channel RCA Output |
| Other Ports | - 1x AC Jack
- 1x eSATA Port - 1x Reset Button -1x RS232 Serial Interface - 2x Front USB 2.0 Ports - 1x Rear USB 3.0 Port - 16x Alarm Inputs - 4x Alarm Outputs |
| Video Ports | 2x HDMI 1x VGA |
| Resolution per Ouputs | - HDMI1: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
- HDMI2: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz - VGA: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
Features |
|
| Package Contents | - HDD Data Cables
- HDD Power Cables - HDD Screws - Installation Guide - Mounting Brackets - Mouse - Power Cord - Rubber Feet - Screws - Terminal Blocks - VIGI Network Video Recorder |
| Features | - 4-ch@8MP, 6-ch@5MP, 8-ch@4MP, 10-ch@3MP, 16-ch@1080P decoding capability
- 16-channel simultaneous playback - 320 Mbps incoming and outgoing bandwidth - Dual independent or simultaneous HDMI output - H.265+ smart video compression - Multi-view display options (1, 4, 6, 8, 9, 16) - ONVIF Profile S/T and CGI interoperability - Remote monitoring through Android, iOS, Chrome, Firefox, and Edge - Support for smart camera-linked alarms (Human/Vehicle detection, line-crossing, intrusion) |
Dimensions |
|
| Dimensions(cm) | 44.0 cm × 4.4 cm × 33.0 cm |
| Weight | 5.0 kg |
Warranty
Warranty:
TP-LINK Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with TP-LINK for you. You may also contact TP-LINK directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by TP-LINK and are final.
