Ubiquiti Horn-5-60 - Directional Horn Antenna, Single-Band, 5GHz, 16dBi, 60 Beamwidth, Dual Polarization
-
Ubiquiti Horn-5-60 | 5GHz | 16dBi | 60 BeamwidthIn stockS/.406.04
Optimize coverage and reduce interference in professional wireless networks with the Ubiquiti Horn-5-60 directional horn antenna. It operates across the 5.155.85GHz range, delivers 16dBi of gain, and provides a 60 beamwidth in both horizontal and vertical polarization, with 30 elevation. Its horn design helps reduce side lobes and back radiation, making it suitable for installations with multiple nearby sectors. It is compatible with selected IsoStation, PrismStation, and airFiber LTU radios.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yape or Bank Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
General |
|
|---|---|
| Brand | Ubiquiti |
| Model | HORN-5-60 |
| Interface | RF Connectors |
| Standards | No Wi-Fi |
| Antennas | Horn antenna, 16 dBi gain. |
| Dimensions(cm) | 16.16 × 17.33 × 17.09 cm |
| Weight | 0.72 kg |
Key Features |
|
| Band | Single Band |
| Frequency | 5.15-5.85 GHz |
| Features | - 5 GHz horn antenna.
- 16 dBi antenna gain. - Horizontal polarization beamwidth (HPOL): 60. - Vertical polarization beamwidth (VPOL): 60. - Elevation beamwidth: 30. - Dual-linear polarization. - Cross-polarization isolation: 17 dB. - Maximum VSWR: 2:1. - Wind survivability: 200 km/h. - Wind loading with PrismStation: 50 N at 200 km/h. - Compatible with IsoStation IS-M5, IS-5AC, PrismStation PS-5AC, and airFiber AF-LTU. |
Warranty
Warranty:
Ubiquiti Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Ubiquiti for you. You may also contact Ubiquiti directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Ubiquiti and are final.
