UNV OEC-R3H-M - Wall-Mounted Mifare Card Reader, IP65, Black
-
UNV OEC-R3H-M | Mifare Card Reader | IP65 | BlackIn stock$26.69* Taxes not included
Brand: Uniview
Model: UN-OEC-R3H-M
The UNV OEC-R3H-M is a contactless Mifare card reader designed for access control and attendance applications. It supports ISO 14443-A and ISO 14443-B protocols, with Wiegand 26/34 and RS485 interfaces and a reading distance of up to 5 cm. Its IP65 protection and indoor/outdoor application support make it suitable for different access control installations.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yappy or ACH Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | UNV |
| Model | UN-OEC-R3H-M |
| Type | Card Reader |
Specifications |
|
| Specifications | - Reader Type: Wall-Mounted Mifare Card Reader
- Card Type: Mifare Card - Authentication Mode: Card - Operating Frequency: 13.56MHz - Interface: Wiegand 26/34, RS485 - Reading Distance: IC Card, maximum 5cm - Protection Level: IP65 - Material: PC - Mount Method: 115 × 73mm junction box / 86 × 86mm junction box - Indicator: Steady blue for normal operation; steady green for 1s when card authentication succeeds; steady red for 1s when card authentication fails |
Dimensions |
|
| Dimensions (mm) | 129 × 88 × 21mm |
| Weight | 134g |
Warranty
Warranty:
UniView Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with UniView for you. You may also contact UniView directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by UniView and are final.
