Uniview UN-XVR301-08F - Hybrid XVR Recorder, 8 Analog Channels + 2 IP Channels, 1080P Lite, Up to 6TB, HDMI, VGA
-
In stock$26.69
-
Uniview UN-XVR301-08F | Hybrid XVR | Up to 6TBIn stock$44.28
-
In stock$77.09
The Uniview UN-XVR301-08F is designed for medium residential and commercial video surveillance systems. Thanks to its self-adaptive pentabrid technology, it offers excellent compatibility with TVI, AHD, CVI, CVBS, and IP cameras, enabling video recording in 1080P Lite resolution and audio-over-coax transmission. Additionally, it features H.265 video compression to optimize storage up to 6TB, simultaneous HDMI/VGA video outputs, and smart motion detection functions to reduce false alarms.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yappy or ACH Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Uniview |
| Model | UN-XVR301-08F |
| Serie | XVR301-F Series |
| Type | DVR |
Recording Details |
|
| Channels | 8 Channels |
| Inputs | 8x Coaxial |
| Audio Inputs | Audio over coaxial cable (supported for TVI cameras) |
| Disk Slots | 1x SATA Interface |
| Max Capacity | Up to 6TB |
| Max Resolution | 1080p |
| Max Frame Rate | - 12fps (Sub stream at D1 resolution)
- 15fps (Main stream at 1080P Lite / 720P / D1 resolutions) - 30fps (Supported analog camera input signals) |
| Compression Format | - H.264
- H.265 |
Outputs Details |
|
| PoE | No |
| Other Ports | - 1 x RJ45 10M/100M self-adaptive Ethernet Interface
- 2 x USB 2.0 (Rear panel) |
| Resolution per Ouputs | - HDMI: 1024x768/60Hz, 1280x720/60Hz, 1280x1024/60Hz, 1600x1200/60Hz, 1920x1080p/50Hz, 1920x1080p/60Hz
- VGA: 1024x768/60Hz, 1280x720/60Hz, 1280x1024/60Hz, 1600x1200/60Hz, 1920x1080p/50Hz, 1920x1080p/60Hz |
Features |
|
| Features | - 8-channel UMD (Ultra Motion Detection)
- Adaptive signal access (TVI, AHD, CVI, CVBS, IP) - Behavior search (VCA Search) - HDMI and VGA simultaneous output - Long transmission distance over coaxial cable - Support analog camera upgrade over coaxial cable - Support audio over coaxial cable (only for TVI cameras) - Support mainstream cameras of ONVIF and RTSP protocols |
Dimensions |
|
| Dimensions(cm) | 19.0 cm × 4.2 cm × 20.2 cm |
| Weight | 0.6 kg |
Warranty
Warranty:
UniView Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with UniView for you. You may also contact UniView directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by UniView and are final.
