Uniview Series 3 - XVR System, 8 Channels, 4K, Up to 16TB, HDMI 4K, VGA
-
Uniview Series 3 | XVR | 8 Channels | 4K 2-SATAIn stock$128.52
Maximize the storage and resolution of your surveillance system with the Uniview UN-XVR302-08U3 professional hybrid video recorder. This high-performance 8-channel device natively handles ultra-high-definition cameras up to 8MP (4K). Featuring a dual-bay SATA design for expanded storage capacity, its true 4K HDMI output, efficient H.265 compression, and smart analytics deliver fluid, flawless, industrial-grade monitoring 24/7.
How to buy this product?
- 1. Add the product to your cart and proceed to checkout
- 2. Select “pickup in a store” or “delivery to house or office”
- 3. Choose your payment method (Debit / Credit Card, Yappy or ACH Transfer) and complete your payment
- 4. After the payment you will receive an email with your delivery or pickup date
Specifications
Model |
|
|---|---|
| Brand | Uniview |
| Model | XVR302-08U3 |
| Serie | UN-XVR302-08U3 |
| Type | DVR |
Recording Details |
|
| Channels | 8 Channels |
| Inputs | 8x Coaxial |
| Audio Inputs | - 1-channel, RCA
- Coaxial audio input (up to 8 channels via compatible TVI cameras) |
| Disk Slots | 2x SATA Interfaces |
| Max Capacity | Up to 16TB |
| Max Resolution | 4k |
| Max Frame Rate | - 8 fps at 8MP
- 12 fps at 5MP - 12 fps at 3K - 15 fps at 4MP - 30 fps at 1080p |
| Compression Format | - H.264
- H.265 |
Outputs Details |
|
| PoE | No |
| Audio Outputs | 1-channel, RCA |
| Other Ports | - 1x RS485 serial interface
- 1x RJ-45 10M/100M/1000M self-adaptive Ethernet interface - 1x CVBS output (BNC) - 2x USB ports (1x USB 2.0 front, 1x USB 3.0 rear) - 4-channel Alarm Output - 8-channel Alarm Input |
| Video Ports | 1x HDMI 1x VGA |
| Resolution per Ouputs | - HDMI: 1024x768/60Hz, 1280x720/60Hz, 1280x1024/60Hz, 1920x1080/50Hz, 1920x1080/60Hz, 3840x2160/30Hz (4K)
- VGA: 1024x768/60Hz, 1280x720/60Hz, 1280x1024/60Hz, 1920x1080/50Hz, 1920x1080/60Hz |
Features |
|
| Features | - 5-in-1 hybrid adaptive connection (TVI, AHD, CVI, CVBS, IP)
- Audio over coaxial cable support for TVI cameras - Dual-light control for UNV analog cameras under TVI - Long distance transmission reliability over coaxial cabling - ONVIF and RTSP mainstream protocols conformance - Simultaneous HDMI and VGA output display - Support for 1-channel CVBS output |
Dimensions |
|
| Dimensions(cm) | 38.00 × 5.30 × 32.60 |
| Weight | 2.00 kg (Without HDD) |
Warranty
Warranty:
Uniarch Standard Warranty
Warranty Period:
1 Year Warranty
Who do I contact if my product has issues?
You can return your product directly to Pana Compu and we will manage any warranty issues directly with Uniarch for you. You may also contact Uniarch directly using your Pana Compu invoice to receive your warranty. All warranty decisions are made by Uniarch and are final.
